Single Garages

Just the right size!

Get the most out of your available space with one of our single garages.

All plans can be adapted to suit your specific needs, with everything from the height and width to the cladding on the outside being customised to suit. We can even include a workshop or extra storage space.

Size
22m²

Plan 1: 6m x 3.6m

Features
  • Personal access door
  • Window options
  • Colours

    Zinc
    Available on Roof, Trim, Doors and Versaclad Cladding.

    Sandstone Grey
    Available on Roof, Trim, Doors and All Cladding.

    Flaxpod
    Available on Roof, Trim, Doors and Superclad Cladding.

    Ebony
    Available on Roof, Trim, Doors and Superclad Cladding.

    Mist Green
    Available on Roof, Trim, Doors and Superclad Cladding

    New Denim Blue
    Available on Roof, Trim, Doors and Superclad Cladding

    Grey Friars
    Available on Roof, Trim, Doors and Superclad Cladding

    Karaka
    Available on Roof, Trims, Doors and Superclad Cladding

    Ironsand
    Available on Roof, Trim, Doors and Superclad Cladding.

    Scoria
    Available on Roof, Trims, Doors and Superclad Cladding

    Desert Sand
    Available on Roof, Trim, Doors and All Cladding

    Titania
    Available on Roof, Trim, Doors and All Cladding

    Please note that the colours displayed online are indicative only and may differ from actual steel colour. Please see your local Versatile for a steel colour sample.
  • Cladding
    Versaclad

    Traditional weatherboard style that uses an exposed nailing pattern

    Versaclad

    Superclad

    An attractive shiplap profile featuring hidden nailing

    Superclad

  • Doors & Windows

    Versatile is able to provide a choice of windows and vehicle door and personal access door options, in a variety of sizes, all supplied with locking devices for added security.

    VEHICLE ACCESS DOORS

    Tilt doors – the traditional single-piece door that pivots on a spring-loaded power arm. Easy-to-use and low cost, it is the most popular choice in New Zealand.

    Roller doors – these move straight up on tracks on either side of the door.

    Sectional doors – like roller doors, horizontal panels move straight up on tracks on either side of the door. An automatic door opener is recommended for use with this door. Sectional doors are available in a variety of profiles; our most popular, Ribline (which can be embossed or smooth) and Pressed Panel as illustrated below.

    OTHER DOORS & WINDOWS

    Personal access door – these are timber-framed and sheathed with steel on both sides for extra security. Personal access doors come complete with waterproof flashings and a push-button lock, for both single or double doors.

    Aluminium joinery – ranchsliders and a range of aluminium windows are also available for your garage.

  • Building Specifications
    Options 1000 Series 600 Series
    Length (min) 3.0m 3.0m
    Length (max) 12.0m No maximum
    Width (min) 3.0m 3.0m
    Width (max) 9.0m 12.0m
    Stud spacing 1000mm centres 600mm centres
    Stud height 2.1m, 2.4m 2.1m, 2.4m, 2.7m, 3.0m
    Cladding types Versaclad, Superclad Versaclad, Superclad
    Superclad colours

    Desert Sand, Ebony, Flaxpod, Grey Friars, Ironsand, Karaka, Mist Green, New Denim Blue, Sandstone Grey, Scoria, and Titania

    Desert Sand, Ebony, Flaxpod, Grey Friars, Ironsand, Karaka, Mist Green, New Denim Blue, Sandstone Grey, Scoria, and Titania

    Versaclad colours

    Desert Sand, Sandstone Grey, Titania, Zinc-coating

    Desert Sand, Sandstone Grey, Titania, Zinc-coating

    Roofing materials Six rib roofing, Corrugate Six rib roofing, Corrugate
    Roof and trim colours

    Desert Sand, Ebony, Flaxpod, Grey Friars, Ironsand, Karaka, Mist Green, New Denim Blue, Sandstone Grey, Scoria, and Titania

    Desert Sand, Ebony, Flaxpod, Grey Friars, Ironsand, Karaka, Mist Green, New Denim Blue, Sandstone Grey, Scoria, and Titania

    Partitions N/A Available
    Truss spacing 2.0m centres as standard and 1.0m optional 1.8m centres as standard and 1.2m optional
    Soffits Front and/or rear Front and/or rear
    Side soffits N/A On 2.4, 2.7, 3.0m stud heights
    Roof pitch 15° 15°, 20°, 25° & 30°
    Hip roof N/A Available
    Gable cladding Board and Batten Board and batten (15° roof pitch only and up to 9m wide). Versaclad or Superclad cladding up the gable
    Standard window size 1 unit = 2 x 450mm wide @ 1m increments
    2, 4 or 6 panes
    550mm wide @ 0.6m increments
    Opening windows May replace standard windows May replace standard windows
    Aluminium windows N/A Various options available
    Tilt door sizes Width: 2.6m, 4.5m (4.5m side entry Tilt Doors only).
    Height: to full stud height
    Width: 2.6m, 3.0m, 3.6m & 4.5m
    Height: as requested, initialise at full stud height.
    Tilt Doors up to & including 3.6m in width = 2650mm, over 3.6m up to and including 4.5m = 2350mm
    Roller door widths 2.6m or 4.5m (2.4m stud only) 2.6m, 3.0m, 3.6m, 4.5m, 4.8m
    Sectional door widths 2.6m or 4.5m (2.4m stud only) 2.6m, 3.0m, 3.6m, 4.5m, 4.8m
    Sectional door profiles Futura and Georgian Futura and Georgian
    Door colours

    Tilt: Desert Sand, Ebony, Flaxpod, Ironsand, Grey Friars, Karaka, Mist Green, New Denim Blue, Sandstone Grey, Scoria, Titania, and Zinc-coating

    Sectional: Desert Sand, Ebony, Flaxpod, Grey Friars, Ironsand, Karaka, Mist Green, New Denim Blue, Sandstone Grey, Scoria, Titania, and Zinc-coating

    Side door 900mm wide 900mm wide
    Open-out side door N/A Available
    Wind zones Low, medium and high Low, medium, high and very high
    Downpipes White PVC i. Titania (for Titania, Mist Green & zinc-coated cladding)
    ii. White PVC
    (for Desert Sand cladding)
    Verandah N/A 600mm increments @ 1.5m wide
    Decks N/A 600mm increments @ 1.5m wide
    Garaports 3.0m, or 3.6m wide @ 1000mm increments long
    Minimum 3m long Side wall only, from front or back of building
    3.0m, or 3.6m wide @ 600mm increments long
    Minimum 3m long
    Workbench 1000mm increments @ 560mm deep, 950mm high 600mm increments @ 560mm deep, 950mm high
    Timber treatment H1.2 as standard. H3.2 bottom plate upgrade available H1.2 as standard. H3.2 bottom plate upgrade available
    Firewalls Available Available
  • Optional Extras

    Upgrade your garage with the addition of these features which make it more attractive or functional.

    Flooring – traditional concrete 100mm thick floor slab with perimeter footings, expansion cuts, floor bolts and reinforcing as required.

    Electrical – Versatile can organise tradeservices to include your electrical, drainlaying and landscaping requirements.

    Fixed pane windows – the standard fixed pane window is supplied with 4mm thick glass.

    Auto door openers – perfect for cold, wet evenings or when it’s difficult to open the door on your own, our auto door openers come with remotes.

    Garaport – the side of your garage can be further extended with a Garaport addition. This provides open-sided protection for another vehicle.

    Verandahs – for added protection from weather and shade from the sun.

    Opening windows – for additional ventilation and access. Window stays restrict the opening space for security.

    Skylights – let the natural light into your garage. Workbench (E) – a strong, sturdy built-in work surface upon
    which to mount a vice or store tools.

    Decking – when combined with a verandah, a deck gives your building an attractive finish. Ramps and stairs are available.

  • Construction

    By utilising the latest timber connections, bracing and pre-cut timber, we have simplified the construction process to enable you to do it yourself, without the need for heavy trade tools. A detailed manual is provided to ensure the step-by-step process is easy to follow.

    Versatile's experienced builders are the professionals when it comes to construction.  We can do as much, or as little as you want. We can handle everything for you from council paperwork, to the finishing touches like driveways and landscaping.

    We also offer kitsets, which come complete in a self-contained pack, with instructions and all required fixings.
