Options |
1000 Series |
600 Series |
Length (min) |
3.0m |
3.0m |
Length (max) |
12.0m |
No maximum |
Width (min) |
3.0m |
3.0m |
Width (max) |
9.0m |
12.0m |
Stud spacing |
1000mm centres |
600mm centres |
Stud height |
2.1m, 2.4m |
2.1m, 2.4m, 2.7m, 3.0m |
Cladding types |
Versaclad, Superclad |
Versaclad, Superclad |
Superclad colours |
Desert Sand, Ebony, Flaxpod, Grey Friars, Ironsand, Karaka, Mist Green, New Denim Blue, Permanent Green, Sandstone Grey, Scoria, Titania
|
Desert Sand, Ebony, Flaxpod, Grey Friars, Ironsand, Karaka, Mist Green, New Denim Blue, Permanent Green, Sandstone Grey, Scoria, Titania
|
Versaclad colours |
Desert Sand, Sandstone Grey, Titania, Zincalume®
|
Desert Sand, Sandstone Grey, Titania, Zincalume®
|
Roofing materials |
Six rib roofing, Corrugate |
Six rib roofing, Corrugate |
Roof and trim colours |
Ebony, Flaxpod, Grey Friars, Ironsand, Karaka, New Denim Blue, Sandstone Grey, Titania and Zinc-coating
|
Ebony, Flaxpod, Grey Friars, Ironsand, Karaka, New Denim Blue, Sandstone Grey, Titania and Zinc-coating
|
Partitions |
N/A |
Available |
Truss spacing |
2.0m centres as standard and 1.0m optional |
1.8m centres as standard and 1.2m optional |
Soffits |
Front and/or rear |
Front and/or rear |
Side soffits |
N/A |
On 2.4, 2.7, 3.0m stud heights |
Roof pitch |
15° |
15°, 20°, 25° & 30° |
Hip roof |
N/A |
Available |
Gable cladding |
Board and Batten |
Board and batten (15° roof pitch only and up to 9m wide). Versaclad or Superclad cladding up the gable |
Standard window size |
1 unit = 2 x 450mm wide @ 1m increments 2, 4 or 6 panes |
550mm wide @ 0.6m increments |
Aluminium windows |
N/A |
Various options available |
Tilt door sizes |
Width: 2.6m, 4.5m (4.5m side entry Tilt Doors only). Height: to full stud height |
Width: 2.6m, 3.0m, 3.6m & 4.5m Height: as requested, initialise at full stud height. Tilt Doors up to & including 3.6m in width = 2650mm, over 3.6m up to and including 4.5m = 2350mm |
Roller door widths |
2.6m or 4.5m (2.4m stud only) |
2.6m, 3.0m, 3.6m, 4.5m, 4.8m |
Sectional door widths |
2.6m or 4.5m (2.4m stud only) |
2.6m, 3.0m, 3.6m, 4.5m, 4.8m |
Sectional door profiles |
Futura and Georgian |
Futura and Georgian |
Door colours |
Tilt: Ebony, Flaxpod, Grey Friars, Ironsand, Karaka, New Denim Blue, Sandstone Grey, Titania, and Zinc-coating
|
Sectional: Ebony, Flaxpod, Grey Friars, Ironsand, Karaka, New Denim Blue, Sandstone Grey, Titania, and Zinc-coating |
Side door |
900mm wide |
900mm wide |
Open-out side door |
N/A |
Available |
Wind zones |
Low, medium and high |
Low, medium, high and very high |
Downpipes |
White PVC |
i. Titania (for Titania & zinc-coated cladding) ii. White PVC |
Verandah |
N/A |
600mm increments @ 1.5m wide |
Decks |
N/A |
600mm increments @ 1.5m wide |
Garaports |
3.0m, or 3.6m wide @ 1000mm increments long Minimum 3m long Side wall only, from front or back of building |
3.0m, or 3.6m wide @ 600mm increments long Minimum 3m long |
Workbench |
1000mm increments @ 560mm deep, 950mm high |
600mm increments @ 560mm deep, 950mm high |
Timber treatment |
H1.2 as standard. H3.2 bottom plate upgrade available |
H1.2 as standard. H3.2 bottom plate upgrade available |
Firewalls |
Available |
Available |
